SKU: WS-C2960S-24PS-L
WS-C2960S-24PS-L - 24x 1GE RJ45, uplink 4x 1G SFP, IOS LAN Base, PoE+ 370W 802.3at, Layer L2, Cisco Catalyst 2960-S Switch
- WS-C2960S-24PS-L
The Catalyst WS-C2960S-24PS-L is a gigabit managed switch with 24 copper ports and 4 SFP uplink ports.
This switch can be stacked with other 2960S series switches and, interestingly, the newer 2960X model using an optional rear-mounted stack module. Such a stack can consist of up to 4 switches. CAB-STK-E cables to connect them are available in 50cm, 1m, and 3m options.
The switch has PoE+ functionality on all 24 ports. The PoE budget for this switch is 370 watts.
It is a L2 layer switch and has LAN Base software installed.
This model allows management via CLI command line, via GUI, as well as via Cisco Network Assistant.
Unikatowy kod produktu
WS-C2960S-24PS-L
Producer
Cisco
Type of device
Switch
Product family
Cisco Catalyst
Software version
LAN Base
Switching layer
2
Type of cooling
Fan
Type of dominant ports
Copper
Dominant ports speed
1G
Dominant ports quantity
24
Dominant Port Standard
RJ45
Uplink ports
Integrated
The speed of the uplink ports
1G
Number of uplink ports
4
Standard of uplink ports
SFP
Standard PoE
PoE+
Standard IEEE
802.3at
Number of PoE ports
24
PoE power available
370W
Maximum power per port
30W
Full-duplex switching speed
176 Gbps
64-byte forwarding speed
41.7 Mpps
Maksimum VLAN count
255
VLAN IDs available
4094
Unicast MAC adres
8000
MTU
9198
Jumbo frame
9216
Stackable
Yes
Stack module included
No
Number of switches in the stack
4
Switching speed in stack
20 Gbps
Working temperature min.
-5°C
Operating temperature max.
45°C
Working humidity min.
10%
Working humidity max.
95%
Typical noise during operation
42 dB
Noise during operation max.
45 dB
Minimal power consumption
54W
Maximum power consumption
55W
PSU power
370W
Emergency power connector
Yes
Power redundancy
No
Flash memory
64 MB
DRAM memory
128 MB
Port USB
Yes
Height
4.5 cm
Width
44.5 cm
Depth
38.6 cm
Weight
5.7 kg
MTBF
245604 h
