SKU: ISR4331/K9
ISR4331/K9
- Router Cisco ISR 4331 (3GE,2NIM,1SM,4G FLASH,4G DRAM,IPB) 100Mbps->300Mbps
The Cisco ISR4331/K9 is part of the Cisco Integrated Services Router (ISR) 4000 series. This router is designed to provide a wide range of services to offices, branch offices and remote locations, while maintaining high performance, security and flexibility. In the previous generation ISR G2 routers, the performance was given in approximate values because the more extensive the configuration was, the more the performance decreased. In the ISR4331/K9 router, 100 Mbps is guaranteed regardless of the number of running services and configuration.
Performance: Offers excellent performance with aggregation throughput from 100 Mbps to 300 Mbps, making it suitable for medium to large branch offices. The router has 4GB RAM and 4GB Flash memory.
Form factor: The ISR4331/K9 has a compact 1RU (rack unit) chassis, which means it can be mounted in a standard network rack.
Ports and Interfaces: It has three WAN interfaces, including 1 Gigabit Ethernet Combo (SFP/RJ45) port, 1 Gigabit Ethernet RJ45 port, and 1 Gigabit Ethernet port in SFP standard. It also has a USB port and a console port.
Expansion cards: The router allows you to expand by additional interfaces with the help of two NIM (Network Interface Modules) and one ESM (Enhanced Services Modules)
Scalability: The ISR4331/K9 is highly scalable and can support additional modules and interfaces for future expansion, such as Voice over IP (VoIP), WAN optimization or security modules.
Security: The Cisco ISR 4000 Series routers have built-in security features, including firewalls, Virtual Private Network (VPN) support, intrusion prevention, and content filtering. However, a security license is then required.
Software: The router runs on the IOS XE operating system, which provides advanced routing, switching and security features.
Management: Can be managed and configured using Cisco's traditional command line interface (CLI) or graphical web interface (GUI).
Power: The router has 1 AC adapter.
Applications: The Cisco ISR4331/K9 is suitable for a variety of networking applications in branch offices, including data routing, voice and video services, VPN connectivity and many more. Additional licenses are required for voice and VPN services. It is often used to connect office branches with the central corporate network.
Support and Licensing: Cisco routers usually require appropriate licenses for certain features and services. This model has IP Base software.
Performance: Offers excellent performance with aggregation throughput from 100 Mbps to 300 Mbps, making it suitable for medium to large branch offices. The router has 4GB RAM and 4GB Flash memory.
Form factor: The ISR4331/K9 has a compact 1RU (rack unit) chassis, which means it can be mounted in a standard network rack.
Ports and Interfaces: It has three WAN interfaces, including 1 Gigabit Ethernet Combo (SFP/RJ45) port, 1 Gigabit Ethernet RJ45 port, and 1 Gigabit Ethernet port in SFP standard. It also has a USB port and a console port.
Expansion cards: The router allows you to expand by additional interfaces with the help of two NIM (Network Interface Modules) and one ESM (Enhanced Services Modules)
Scalability: The ISR4331/K9 is highly scalable and can support additional modules and interfaces for future expansion, such as Voice over IP (VoIP), WAN optimization or security modules.
Security: The Cisco ISR 4000 Series routers have built-in security features, including firewalls, Virtual Private Network (VPN) support, intrusion prevention, and content filtering. However, a security license is then required.
Software: The router runs on the IOS XE operating system, which provides advanced routing, switching and security features.
Management: Can be managed and configured using Cisco's traditional command line interface (CLI) or graphical web interface (GUI).
Power: The router has 1 AC adapter.
Applications: The Cisco ISR4331/K9 is suitable for a variety of networking applications in branch offices, including data routing, voice and video services, VPN connectivity and many more. Additional licenses are required for voice and VPN services. It is often used to connect office branches with the central corporate network.
Support and Licensing: Cisco routers usually require appropriate licenses for certain features and services. This model has IP Base software.
Unikatowy kod produktu
ISR4331/K9
Type of device
Router
Producer
Cisco
Licenses
IP Base
Software type
IOS-XE
Total number of WAN ports
2
Number of 1G LAN ports
1
Number of LAN COMBO ports
2
LAN SFP ports
1
Number of NIM sockets
2
Number of SM sockets
1
Number of ISC sockets
1
Port USB
Yes
Throughput [Mbps]
100
Performance unlocked by license [Mbps]
300
Network monitoring
NetFlow
Flash memory [GB]
4
Maximum flash memory [GB]
16
DRAM memory [GB]
4
Maximum DRAM [GB]
16
Minimum operating temperature [°C]
0
Maximum operating temperature [°C]
40
Minimum humidity.[%]
5
Maksimum humidity[%]
85
Typical noise during operation [dB]
61,20
Maksimum noise [dB]
81,60
Redundant PSU
No
Height [RU]
1
Height [cm]
4,44
Width [cm]
43,82
Depth [cm]
43,82
MTBF [h]
587250
