SKU: CGS-2520-24TC
CGS-2520-24TC
- Switch Cisco CGS 2520 Switch, front/rear cabling w/2GE, 24 x 10/100 copper
Unikatowy kod produktu
CGS-2520-24TC
Producer
Cisco
Type of device
Switch
Product family
Cisco SMB
Software version
LAN Base
Switching layer
2
Type of cooling
Passive
Type of dominant ports
Copper
Dominant ports speed
1G
Dominant ports quantity
24
Dominant Port Standard
RJ45
Uplink ports
Integrated
The speed of the uplink ports
1G
Number of uplink ports
2
Standard of uplink ports
SFP/RJ45 Combo
Standard PoE
PoE+
Standard IEEE
802.3at
Number of PoE ports
24
PoE power available
65W
Maximum power per port
30W
PoE with two power supplies.
Yes
PoE power available with two power supplies
170W
Full-duplex switching speed
8.8 Gbps
64-byte forwarding speed
6.55 Mpps
Maksimum VLAN count
4096
Unicast MAC adres
8000
MTU
9000
Stackable
No
Working temperature min.
-40°C
Operating temperature max.
70°C
Working humidity min.
5%
Working humidity max.
95%
Minimal power consumption
43W
Maximum power consumption
213W
Power redundancy
Yes
Redundant power supply included
No
Flash memory
1 GB
DRAM memory
256 MB
Port USB
Yes
Height
4.5 cm
Width
45 cm
Depth
36 cm
Weight
4.5 kg
MTBF
660730 h
